Page 8
Water
Pump
Connecting at Engine
OFF
OFF
OFF TES T
SYS TEM VAC UUM
SYS TEM PR ESS URE
FILL RAD IATO R & O VER FLO W
EXC HAN GE C OO LAN T
EM PTY WA STE TAN K
LOW ER R ADIA TOR & O VER FLO W
& O VER FLO W
LOW ER R ADIA TOR
EX CHA NG E C OO LAN T OR
FILL RAD IATO R & OVE RFL OW
EM PTY WA STE TAN K
Overflow
Radiator
Black Hose
Green Hose
Radiator
Hose Step
Adapters
Connecting at Radiator
Engine
Block
Green Hose
Black Hose
SYS TEM VA CUU M
EXC HAN GE CO OLAN T O R
FILL RAD IATO R & OVE RFL OW
OFF
OFF
TES T
SYS TEM PR ESS URE
FILL RA DIAT OR & O VER FLO W
EXC HAN GE C OOL ANT
EMP TY W ASTE TAN K
LO WER RA DIAT OR & O VER FLO W
EM PTY W ASTE TAN K
Engine
Block
OFF
& O VER FLO W
LOW ER R ADIA TOR
Heater
Core
Hose
Adapter
Adapters
Step
Hose
Adapter
Radiator
Radiator
Hose
Water
Pump
Overflow
Heater
Core
CONNECTING TO THE COOLANT SYSTEM
The MCX-2 can be connected to the cooling system in either of the configurations
shown below. The choice is dependent on the ease of accessability to the hose
connections.
1. Disconnect the radiator hose from either the engine or the radiator.
2. Select an Adapter Hose with the same inner diameter as the radiator hose and
connect at the point the radiator hose was disconnected using a clamp.
3. Install Step Adapters in the Adapter Hose and the radiator hose using clamps.
Make sure the outside diameter of the Step Adapters is the same as the inner
diameter of the radiator hose.
4. Connect the Green and Black hoses from the MCX-2 to the two Step Adapters
as shown in the illustrations. See next page for special hookups.
5. Open the valves on the two Step Adapters.
