Page 31
— 31 —
XIII. UNIT/SHIP WEIGHTS
Cooling Coil Weight Adder (Approximate)
DX COIL
(CA) Capacity
4 Row
6 Row
10, 15
70 lbs.
95 lbs.
20, 25, 50
95 lbs.
130 lbs.
30, 35, 60, 70
119 lbs.
166 lbs.
40, 80
130 lbs.
182 lbs.
CHILLED WATER COIL
(CA) Capacity
4 Row
6 Row
10, 15
170 lbs.
222 lbs.
20, 25, 50
215 lbs.
287 lbs.
30, 35, 60, 70
264 lbs.
359 lbs.
40, 80
284 lbs.
389 lbs.
Motor Shipping Weight (lbs) - Approximate
1 - (115/1/60)
2 - (208/1/60)
3 - (230/1/60)
1
ODP
2
TE
3
PEODP
4
PETE
1
ODP
2
TE
3
PEODP
4
PETE
1
ODP
2
TE
3
PEODP
4
PETE
1/2 HP
20.0
24.0
32.0
30.0
21.0
24.0
32.0
21.0
24.0
32.0
30.0
3/4 HP
23.0
30.0
30.0
41.0
23.0
30.0
30.0
25.0
30.0
30.0
41.0
1 HP
32.0
32.0
40.0
44.0
32.0
32.0
32.0
32.0
40.0
44.0
1-1/2 HP
40.0
41.0
47.0
57.0
40.0
41.0
40.0
41.0
47.0
57.0
2 HP
42.0
67.0
65.0
64.0
50.0
67.0
42.0
48.0
65.0
64.0
3 HP
78.0
86.0
78.0
86.0
78.0
86.0
90.0
5 HP
87.0
87.0
99.0
95.0
7-1/2 HP
134.0
138.0
134.0
138.0
10 HP
165.0
140.0
161.0
15 HP
4 - (208/3/60)
5 - (230/3/60)
6 - (460/3/60)
1
ODP
2
TE
3
PEODP
4
PETE
1
ODP
2
TE
3
PEODP
4
PETE
1
ODP
2
TE
3
PEODP
4
PETE
1/2 HP
19.0
18.0
22.0
22.0
19.0
18.0
22.0
22.0
19.0
18.0
22.0
22.0
3/4 HP
27.0
26.0
27.0
27.0
22.0
27.0
31.0
27.0
22.0
27.0
31.0
1 HP
24.0
26.0
36.0
37.0
24.0
26.0
36.0
37.0
24.0
26.0
36.0
37.0
1-1/2 HP
28.0
34.0
40.0
42.0
28.0
34.0
40.0
42.0
28.0
34.0
40.0
42.0
2 HP
35.0
46.0
49.0
35.0
42.0
46.0
49.0
35.0
42.0
46.0
49.0
3 HP
48.0
69.0
69.0
48.0
69.0
69.0
48.0
69.0
69.0
5 HP
76.0
77.0
76.0
77.0
76.0
77.0
7-1/2 HP
117.0
136.0
117.0
136.0
117.0
136.0
10 HP
128.0
158.0
128.0
158.0
128.0
158.0
15 HP
217.0
255.0
217.0
255.0
217.0
255.0
7 - (575/3/60)
1
ODP
2
TE
3
PEODP
4
PETE
1/2 HP
22.0
18.0
3/4 HP
20.0
22.0
1 HP
28.0
26.0
33.0
38.0
1-1/2 HP
40.0
42.0
2 HP
46.0
48.0
3 HP
66.0
69.0
5 HP
74.0
91.0
7-1/2 HP
114.0
143.0
10 HP
145.0
153.0
15 HP
234.0
302.0
Motor Type (MT) Legend:
ODP - Open Drip Proof
TE - Totally Enclosed
PEODP - Premium Effi ciency Open Drip Proof
PETE - Premium Effi ciency Totally Enclosed
Indoor Arrangement [IA] "B, D, G, K"
Shipping Weights (lbs.)
Arrangement [IA]
Capacity [CA]
B
D
G
K
10
637
803
929
15
662
828
954
20
785
982
972
1103
25
812
1009
1021
1149
30
937
1163
1186
1321
30
983
1209
1238
1374
40
1048
1287
1314
1460
50
1144
1340
1349
1476
60
1318
1543
1565
1701
70
1389
1613
1634
1770
80
1490
1729
1748
1893
