Page 26

— 26 —
XI. DIMENSIONAL DATA — ARRANGEMENTS
Table #T4088-B, D
CAPACITY
A B F† G J L U
V
Dia.**
10
32-7/8
15-9/16
16-3/8
31-1/16
24
77-3/8
73-5/8
4
(835) (395) (416) (789) (610) (1965)
(1870) (102)
15
32-7/8
18-5/16
20-1/2
31-1/16
24
77-3/8
73-5/8
4
(835) (465) (521) (789) (610) (1965)
(1870) (102)
20
43-7/8
23-13/16
23-1/2
42-1/16
35
77-3/8
73-5/8
5
(1114) (605) (597) (1068) (889) (1965) (1870) (127)
25
43-7/8
29-5/16
31-1/2
42-1/16
35
77-3/8
73-5/8
5
(1114) (745) (800) (1068) (889) (1965) (1870) (127)
30
54-7/8
34-13/16
34-1/4
53-1/16
46
77-3/8
73-5/8
6
(1394) (884) (870) (1348) (1168) (1965) (1870) (152)
35
54-7/8
40-5/16
42-1/4
53-1/16
46
77-3/8
73-5/8
6
(1394) (1024) (1073) (1348) (1168) (1965) (1870) (152)
40
60-3/8
45-13/16
48
58-9/16
51-1/2
77-3/8
73-5/8
6
(1534) (1164) (1219) (1487) (1308) (1965) (1870) (152)
50
43-7/8
29-5/16
31-1/2
42-1/16
35
103 3/8
99-5/8
5
(1114) (745) (800) (1068) (889) (2626) (2530) (127)
60
54-7/8
34-13/16
34-1/4
53-1/16
46
103 3/8
99-5/8
6
(1394) (884) (870) (1348) (1168) (2626) (2530) (152)
70
54-7/8
40-5/16
42-1/4
53-1/16
46
103-3/8
99-5/8
6
(1394) (1024) (1073) (1348) (1168) (2626) (2530) (152)
80
60-3/8
45-13/16
48
58-9/16
51-1/2
103-3/8
99-5/8
6
(1534) (1164) (1219) (1487) (1308) (2626) (2530) (152)
NOTES:
Dimensions are in inches (Dimensions in parenthesis are in millimeters)
* These dimensions are outside damper measurements.
† “F” Dimension is the recommended clearance to service the burner drawer.
“J” is an outside dimension for return air dampers.
**“V” Dia. = Flue Opening (ME - Power Vent Units Only); the 4” to 5” reducer adaptor is to be fi eld supplied/installed for unit capacities 10 & 15.
The 5” to 6” increaser adaptor is supplied by the manufacturer for unit capacities 30, 35, 40, 60, 70, & 80 (required for each
furnace’s fl ue).
Gas Inlet sizes: Natural Gas: Capacities 10 thru 20 = 1/2”; Capacities 25 thru 80 = 3/4”.
LP Gas: Capacities 10 thru 20 = 1/2”; Capacities 25 thru 80 = 1/2” or 3/4”.
All dimensional drawings for the “B” and “D” Indoor Arrangement are shown as Dual Furnace Unit Capacities (50/80). The dimensional data for
Single Furnace Capacities (10/40) are tabulated in table 6 accordingly for all capacities.
