Sterling ME - Manual (Page 28)

— 28 —
Arrg G Arrg K
CAPACITY A B F G J L M Q R U U V Dia.**
10 32-7/8 15-9/16 16-3/8 31-1/16 24 113-1/2 21-1/4 60-5/16 26-5/8 108-1/2 134-1/2 4
(835) (395) (416) (789) (610) (2883) (540) (1532) (676) (2756) (3416) (102)
15 32-7/8 18-5/16 20-1/2 31-1/16 24 113-1/2 20-1/4 60-5/16 26-5/8 108-1/2 134-1/2 4
(835) (465) (521) (789) (610) (2883) (514) (1532) (676) (2756) (3416) (102)
20 43-7/8 23-13/16 23-1/2 42-1/16 35 113-1/2 20-1/4 60- /16 26-5/8 108-1/2 134-1/2 5
(1114) (605) (597) (1068) (889) (2883) (514) (1532) (676) (2756) (3416) (127)
25 43-7/8 29-5/16 31-1/2 42-1/16 35 113-1/2 20-1/4 60-5/16 26-5/8 108-1/2 134-1/2 5
(1114) (745) (800) (1068) (889) (2883) (514) (1532) (676) (2756) (3416) (127)
30 54-7/8 34-13/16 34-1/4 53-1/16 46 113-1/2 20-1/4 60-5/16 26-5/8 108-1/2 134-1/2 6
(1394) (884) (870) (1348) (1168) (2883) (514) (1532) (676) (2756) (3416) (152)
35 54-7/8 40-5/16 42-1/4 53-1/16 46 113-1/2 20-1/4 60-5/16 26-5/8 108-1/2 134-1/2 6
(1394) (1024) (1073) (1348) (1168) (2883) (514) (1532) (676) (2756) (3416) (152)
40 60-3/8 45-13/16 48 58-9/16 51-1/2 113-1/2 21-1/4 60-5/16 26-5/8 108-1/2 134-1/2 6
(1534) (1164) (1219) (1487) (1308) (2883) (540) (1532) (676) (2756) (3416) (152)
50 43-7/8 29-5/16 31-1/2 42-1/16 35 139-1/2 20-1/4 60-13/16 35-1/8 134-1/2 160-1/2 5
(1114) (745) (800) (1068) (889) (3543) (514) (1545) (892) (3416) (4077) (127)
60 54-7/8 34-13/16 34-1/4 53-1/16 46 139-1/2 20-1/4 60-13/16 35-1/8 134-1/2 160-1/2 6
(1394) (884) (870) (1348) (1168) (3543) (514) (1545) (892) (3416) (4077) (152)
70 54-7/8 40-5/16 42-1/4 53-1/16 46 139-1/2 20-1/4 60-13/16 35-1/8 134-1/2 160-1/2 6
(1394) (1024) (1073) (1348) (1168) (3543) (514) (1545) (892) (3416) (4077) (152)
80 60-3/8 45-13/16 48 58-9/16 51-1/2 139-1/2 21-1/4 60-13/16 35-1/8 134-1/2 160-1/2 6
(1534) (1164) (1219) (1487) (1308) (3543) (540) (1545) (892) (3416) (4077) (152)
12 60-3/8 45-13/16 48 58-9/16 51-1/2 165-1/2 21-1/4 86-1/8 35-1/8 160-1/2 186-1/2 6
(1534) (1164) (1219) (1487) (1308) (4204) (540) (2188) (892) (4077) (4737) (152)
NOTES:
The dimensional data is tabulated for single and dual furnace capacities accordingly.
Using table 7 (#T4088K/T4089G), Capacities 10 & 15 apply only to Arrangement “K”; Capacity 12 applies only to Arrangement “G”.
Dimensions are in inches (Dimensions in parenthesis are in millimeters).
* These dimensions are outside damper measurements.
† “F” Dimension is the recommended clearance to service the burner drawer.
“J” is an outside dimension for return air dampers.
** “V” Dia. = Flue Opening (ME - Power Vent Units Only); the 4” to 5” reducer adaptor is to fi eld installed for unit capacities 10 & 15.
The 5” to 6” increaser adaptor is supplied by the manufacturer for unit capacities 30, 35, 40, 60, 70, 80 & 12 (required for each
furnace’s fl ue).
Gas Inlet sizes: Natural Gas: Capacities 10 thru 20 = 1/2”; Capacities 25 thru 12 = 3/4”.
LP Gas: Capacities 10 thru 20 = 1/2”; Capacities 25 thru 12 = 1/2” or 3/4”.
DIMENSIONAL DATA — ARRANGEMENTS
Table #T4088K/T4089G
