D4430
Fan Guard
Fan Blade
Hardware
Hardware
Motor
22
IDENTIFICATION OF PARTS
PROPELLER UNIT HEATERS
Figure 13
Propeller Parts
1. HEAT EXCHANGER
2. FLUE COLLECTOR
3. BURNER DRAWER
Figure 15
Internal Furnace Components
Figure 16
Burner Assy' Parts
115/1/60 MOTOR
FAN GUARD
FAN BLADE
HARDWARE
ELECTRODE/
SENSING LEAD
LOCATION
Figure 14
Components Parts
(Bottom View)
