IM 12B06K06-E-E
7
8. Model and Suffix Codes
RF20M (EXmatic 450) Pneamatic Control Unit for Retractables
Housing -GF Plastic Housing
-SS Stainless Steel Housing
Cleaning -C1 For One Cleaning Solution valve
-C2 For Two Cleaning Solutions valves
Drain -ND Without
-N1 With Drain Valve
Connection hose -NH Without
-03 3m Length
-05 5m Length
-10 10m Length
Fastener -NF Without
-EX Fastening Angle Exatrac
-RE Fastening Angle Hamilton Retractex
Spareparts
Partnumber Description
10/2-083-70-001 Wall Mounting Set (for plastic housing)
10/2-083-70-002 Wall Mounting Set (for stainless steel housing)
10/2-083-70-003 Post Mounting Set (for plastic and stainless steel)
10/2-095-70-001 Membrane-valve PVDF/FPM (single) G3/8”; Air Ø6; DN12 PN6 NC for Cleaning solution or drain
10/2-095-70-002 Cleaning valve set PVDF/FPM with 2 membrane valves for 1 cleaning solutions and one drain, connectors,
PTFE-tubing and mounting brackets included
10/2-095-70-003 Cleaning valve set PVDF/FPM with 3 membrane valves for 2 cleaning solutions and one drain, connectors,
PTFE-tubing and mounting brackets included
