Legend: metric mm [inches – Alliance Laundry Systems WFF135 User Manual
Page 21
315 [12.4]
B
332 [13.07]
106.5 [4.19]
202 [7.95]
267 [10.51]
969 [
38.
15]
894 [
35.
2]
302 [
11.
89]
936 [
36.
85]
A
843 [
33.
19]
209 [8.23]
84 [
3.
31]
L
K
109 [4.29]
F
E
D
G
I
C
780 [30.71]
1204 [
47.
4]
1175 [
46.
26]
455 [
17.
91]
640 [25.2]
70 [2.76]
70 [2.76]
220 [8.66]
33 [1.3]
84 [3.31]
260 [10.24]
28 [1.1]
410 [16.14]
82 [3.23]
816 [32.12]
760 [29.92]
21
3
Dimensions WFF135, IWF135, IWF030, CWF135, CWF030
A. Ventilation soap dispenser
B. Liquid soap connetions
C. Hard water connections 3/4"
D. Warm water connections 3/4"
E. Soft water connections 3/4"
F. Main switch
G.Electrical connections
I. Ventilation tub
K. Drain valve
L. Steam connections
Legend: metric mm [inches]
