5-2
<5. USING THE BT200 FUNCTIONS >
IM 01C00A11-01E
F0501-2.EPS
UP LOAD
MODEL
EJ110-DM
UPLOAD start?
push ENTER key
ESC
[F3] PRNT
[F4] ESC
➝
Print uploaded data.
(See section 5.2(5).)
➝
Return to the
function panel.
3
᭺
3. The model name of the
connected instrument is
displayed, check it and press
[ENT].
UP LOAD
communi.
MODEL
EJ110-DM
UPLOADING
please wait...
UP LOAD
MODEL
EJ110-DM
UPLOAD complete
F3:print data
PRNT
ESC
4. An upload is executed and a
transfer starts.
Panel is displayed while the
transfer is in progress.
4
᭺
5
᭺
5. The transfer is complete
when panel appears.
4
᭺
5
᭺
Because the data is written to the BT200’s nonvolatile
memory, it is preserved intact even when the terminal
is switched off.
(2) GLOBAL COPY (DOWNLOAD)
Downloading copies the settings stored in the BT200
into other instruments in a batch, but not into different
models.
MENU
A:DISPLAY
B:SENSOR TYPE
HOME
SET
ADJ
ESC
F0502-1.EPS
FUNC
1.MENU
2.UPLOAD TO HHT
3.DOWNLOAD TO INST
4.PRINT ALL DATA
HOME
SET
ADJ
1. Connect the BT200 to the
other instrument and make it
ready for communication.
Press [F4] ESC on the menu
panel to call panel .
2. Select ‘3. DOWNLOAD TO
INST’ and press [ENT].
2
᭺
1
᭺
2
᭺
