Ground Cable Connection
The grounding terminals are located on the inside and outside of the terminal area.
Connect the cable to grounding terminal in accordance with wiring procedure 1) or 2).
1) Internal grounding terminal
If the power cable is a shielded cable, the
shield should be grounded at the terminal
marked as below.
2) External grounding terminal
M4 screw
(Bottom of the enclosure)
Wiring Procedure for Grounding Terminals
