6. Information Provision Web Site
For FieldMate and/or PRM users, the user’s web site has been already in operation as follows:
https://voc.yokogawa.co.jp/PMK/Top.do
The FlowNavigator category within the above web site provides the latest software operation environment supporting
information such as documents and update programs.
After registration as a FieldMate user, you can find the “Download” → “FlowNavigator” menu by clicking the information icon on
the top menu. Entering your FSA120 license number allows you to access the information menu for “FlowNavigator”.
Appendix A Flow Parameters Download Procedure
The basic procedure for downloading the flow parameters to a device is as follows. Refer to Figure A-1, A-2.
Step1
Upload from Device
Perform “Upload from Device” so that the setting parameters (“Device Flow Parameters” and “Device General Parameters”) in
the device are saved to the offline database on your PC.
The parameters will then be displayed in the Offline Parameter screen.
Step2
Flow Configuration
Perform Flow configuration in accordance with the guidance in the Flow Configuration Wizard. “Device Flow Parameters” are
output by Flow Configuration Wizard.
Save “Device Flow Parameters” as XMV file (EJXMVTool) or VMV file (DYFMVTool) in the last menu, and click the “Apply”
button.
“Device Flow Parameters” are then stored to the offline database on your PC.
NOTE
Clicking on Apply does not download the flow parameters to the device.
Step3
Download to Device
Perform “Download to Device”. “Device Flow Parameters” will then be downloaded together with the “Device General
Parameters” to the device.
