CARBON MONOXIDE MONITOR MODEL CM200 SERIES
TYPICAL APPLICATIONS:
• Parking Garages • Fire Stations
• Vehicle Maintenance Shops • Police Stations
• Car Dealers • Post Offices
• Warehouses • Ice Arenas
FEATURES:
• Self-Checking feature for sensor failure
• Sensor LED indication
- Operation Normal - Power ON
- Warning Stage - Alarm Stage
• Completely solid state for long life
• Relay outputs for control and alarming
• User adjustable Warning Level
GENERAL DESCRIPTION:
TOXALERT’S Model CM200 Series monitors are
compact, solid-state, low maintenance, cost effective
carbon monoxide monitors designed for fixed installation,
continuous monitoring.
The Model CM200 Series consists of three separate
monitors. Model CM201 has a single stage audible alarm;
Model CM202 has two stages of relay outputs, and Model
CM203 has a first stage relay output and a second stage
audible alarm. All models are microprocessor based with
temperature and humidity compensation for stability. The
solid state semiconductor-type sensor and associated
electronics ensure trouble-free, long-term operation, for
there are no pumps, filters or chemical cells to replace or
maintain.
TOXALERT INTERNATIONAL, INC., P.O. BOX 159, MOUND, MINNESOTA 55364 (952) 472-4541 FAX (952) 472-4960
Visit our website at www. toxalert. com
TM TOXALERT
DATA
SHEET
CM202
• User adjustable Alarm Level
• Operating range meets OSHA std. 1910.1000
• Compact Nema 1 enclosure
• No maintenance except periodic calibration
checks
