REFRIGERANT REMOTE ALARM PANEL

MODEL RRAP – 24


USED IN TYPICAL APPLICATIONS SUCH AS:

GENERAL DESCRIPTION:
TOXALERT’S Refrigerant Remote Alarm Panel, when used in conjunction with a refrigerant or other
monitoring system, can provide alarm signaling (audible alarm with visual indication) in separate areas
where remote alarm indication is needed. It warns of possible problem situations, such as leakage of
refrigerant gases and oxygen depletion. It is therefore also useful in preventing entry into or
occupancy of an area where a hazardous condition may exist, and allows for remote actuation of a
purge exhaust fan. The Refrigerant Remote Alarm Panel can be used in conjunction with systems
furnished by TOXALERT INTERNATIONAL, Inc., or integrated into any other control system.

FEATURES:

ƒ Compact Nema 1 Enclosure

ƒ Audible

Alarm

ƒ Visual Indicator
ƒ Resettable pushbutton silence
ƒ Purge Switch

SPECIFICATIONS:

Alarm functions:

Alarm horn with push button silence, 3.5kHz tone @ 95 dB, red LED indicator

Input Power:

24 VDC, 12.5 mA max

24 VAC, 12.5 mA max

Operating:

Temperature: -68°F to 140°F (-56°C to +60°C)

Relative Humidity: 5 to 95% non-condensing


Enclosure:

Dimensions - 6.63” x4.67” x 3.64” (168.4mm x 118.5mm x 92.4mm)

Weight:

2.2

lbs

Type - Nema 1

Material - Gray polycarbonate

ƒ Mechanical Rooms
ƒ Ice Arenas
ƒ Refrigerated Warehouses
ƒ Refrigerant Storage
ƒ Supermarkets
ƒ Medical Facilities
ƒ Production Areas

TOXALERT INTERNATIONAL, INC

., P.O. BOX 159, MOUND, MINNESOTA 55364 ● PHONE: 952/472-4541 ● FAX 952/472-4960

Visit our website @ www.toxalert.com
