16
Width, deflector down 49.5" (126 cm)
Width, deflector up 36.5" (93 cm)
Length 62" (157.5 cm)
Weight 726 lbs (329 kg)
Width, deflector down 62" (157.5 cm)
Width, deflector up 49" (124 cm)
Length 59.75" (152 cm)
Weight 815 lbs (370 kg)
Width, deflector down 66" (168 cm)
Width, deflector up 53" (135 cm)
Length 59.75" (152 cm)
Weight 823 lbs (373 kg)
36" (91 cm) Stander Intensity
48" (122 cm) Stander Intensity
52" (132 cm) Stander Intensity
Critical Application
Thread
Locker
Torque Range
ft-lbs / Nm
Wheel motor bolts (Securing motor
to support)
Loctite 2760 40-50 / 54-68 Nm
Clutch to engine shaft Loctite 2760 50-55 / 68-75 Nm
Wheel hub to wheel motor N/A 138-158 / 187-214 Nm
Wheel lug nuts N/A 80-90 / 108-122 Nm
Split Hub (Spindle & Drive) (Gr 8) N/A 13-17 / 18-23 Nm
Blade Bolts N/A 70-80 / 95-108 Nm
Deck Lift Adj. Hardware N/A 45 / 61 Nm
Torque Specifications
Fuel System

Capacity: 5.5 Gal. (20.8 L)

Type of Fuel: Unleaded regular gasoline, minimum 85 octane. Do not use gasoline containing
more than 10% ethanol. Do not mix oil with gasoline.

Fuel Filter: In line

Fuel shut off: On, Off located on fuel tank
Safety Interlock System

PTO switch must be disengaged, brake engaged and the control handles in the neutral and
locked position to start the engine.

Operator must have feet on the platform to engage the PTO and brake off or engine will stop.
Drive System:

Two Hydro Gear 10cc variable displacement piston pumps

Two Hydro Gear 12cc wheel motors
Hydro Oil System

Hydro Oil: fully SYNTHETIC motor oil: Mobil-1 15W-50

Hydro Filter: Spin-on, 25 micron, no bypass / PN 34490002

Total Capacity: 3 qts (2.8 L)

Tank Fill Level: Fill until fluid comes to the center of the sight glass.
