Wright Serial # 69788 and Higher - Manual (Page 28)

28
6.8 Battery Service
The battery is 12 volts and is a maintenance free battery. Charge
the battery only if it will not start the mower properly. Remove the
battery from the mower before charging. Follow the instructions
of the battery charger for proper and safe charging of the battery.
To access the battery, first, park the machine safely. Remove the
retainer knob (A) and remove battery cover (B).
6.9 Parking Brake Adjustment
To test if the parking brake needs adjustment, inflate tires to the correct pressures.
Stop machine on a maximum 17 degree slope and apply the brake. Properly adjusted
brakes will prevent the wheels from turning. If the drive wheels turn, a brake
adjustment will be necessary. Adjustment nuts are located between the fuel tank and
upright.
To adjust brake:

Loosen adjustment nuts. (A)

Bring brake shoe down until contact is made with the tire. (B)

With brake shoe making contact with the tire, move the brake handle to approximately
30 degrees (C) and tighten adjustment nuts. (A)

Test parking brake. Adjust again, if required
6.10 Lubrication
The Wright Stander I is made with sealed bearings, oil based bushings and with limited
grease fittings therefore only the front caster pivots need to be greased. Grease yearly
by either, removing the ¼-28 bolt and install a grease fittings or by removing the dust
cap, disassembling and re-packing the wheel bearings. Use Mobil Polyrex-EM grease.
Use care filling with grease gun as too much pressure could blow out the grease seal.
6.11 Cutting Blades
In order to maintain the best cut, it is important that the blades are well sharpened and not damaged. Bent or
cracked blades or blades with large nicks need to be replaced. Blades must be balanced after sharpening.
To change the blades:

Stop engine, remove the key and wait for all moving parts to stop.

Engage the parking brake

Lift front of mower and secure in the raised position with jack stands.

Remove the blade bolt by turning counterclockwise.

Apply anti-seize to the blade bolt.

Install new or re-sharpened blade, start mounting bolt by hand. (Ensure the blade spacers are reinstalled
with the same qty and location)

Torque blade bolt to 70-80 ft/lbs / 95-108 Nm
A
B
A
B
C
Dust Cap
Grease
fitting
port
