Series 922 – Watlow Series 922 Retrofit User Manual

Page 8

Series 922

Line Voltage

Input

Control Mode

Action

Output

Set Point

Mounting

Retrofit

See Notes

Below

922A-ABB0-B000

115/230 VAC

J t/c/Proc

Progammable

Dual 0.5A SSR/0.5A SSR

Profiling

1/4 DIN

F4DH-KKKK-01RG

6, 16

922A-ABB0-C000

115/230 VAC

J t/c/Proc

Progammable

Dual 0.5A SSR/0.5A SSR

Profiling

1/4 DIN

F4DH-KKKK-01RG

6, 16

922A-ACC0-A000

115/230 VAC

J t/c/Proc

Progammable

Dual Sw dc/Sw dc

Profiling

1/4 DIN

F4DH-CCCC-01RG

922A-ACC0-B000

115/230 VAC

J t/c/Proc

Progammable

Dual Sw dc/Sw dc

Profiling

1/4 DIN

F4DH-CCCC-01RG

922A-ACC0-C000

115/230 VAC

J t/c/Proc

Progammable

Dual Sw dc/Sw dc

Profiling

1/4 DIN

F4DH-CCCC-01RG

922A-AFB0-A000

115/230 VAC

J t/c/Proc

Progammable

Dual 4-20MA/0.5A SSR

Profiling

1/4 DIN

F4DH-FKFK-01RG

922A-AFB0-B000

115/230 VAC

J t/c/Proc

Progammable

Dual 4-20MA/0.5A SSR

Profiling

1/4 DIN

F4DH-FKFK-01RG

6, 16

922A-AFB0-C000

115/230 VAC

J t/c/Proc

Progammable

Dual 4-20MA/0.5A SSR

Profiling

1/4 DIN

F4DH-FKFK-01RG

6, 16

922A-BBB0-A000

115/230 VAC

K t/c/Proc

Progammable

Dual 0.5A SSR/0.5A SSR

Profiling

1/4 DIN

F4DH-KKKK-01RG

922A-BBB0-B000

115/230 VAC

K t/c/Proc

Progammable

Dual 0.5A SSR/0.5A SSR

Profiling

1/4 DIN

F4DH-KKKK-01RG

6, 16

922A-BBB0-C000

115/230 VAC

K t/c/Proc

Progammable

Dual 0.5A SSR/0.5A SSR

Profiling

1/4 DIN

F4DH-KKKK-01RG

6, 16

922A-BCC0-A000

115/230 VAC

K t/c/Proc

Progammable

Dual Sw dc/Sw dc

Profiling

1/4 DIN

F4DH-CCCC-01RG

922A-BCC0-B000

115/230 VAC

K t/c/Proc

Progammable

Dual Sw dc/Sw dc

Profiling

1/4 DIN

F4DH-CCCC-01RG

922A-BCC0-C000

115/230 VAC

K t/c/Proc

Progammable

Dual Sw dc/Sw dc

Profiling

1/4 DIN

F4DH-CCCC-01RG

922A-BFB0-A000

115/230 VAC

K t/c/Proc

Progammable

Dual 4-20MA/0.5A SSR

Profiling

1/4 DIN

F4DH-FKFK-01RG

922A-BFB0-B000

115/230 VAC

K t/c/Proc

Progammable

Dual 4-20MA/0.5A SSR

Profiling

1/4 DIN

F4DH-FKFK-01RG

6, 16

922A-BFB0-C000

115/230 VAC

K t/c/Proc

Progammable

Dual 4-20MA/0.5A SSR

Profiling

1/4 DIN

F4DH-FKFK-01RG

6, 16

Event Board

A007-1732-18B2

115/230 VAC

Dual 0.5A SSR

Open Bd

A007-1732-F4B2

A007-1732-18B8

115/230 VAC

Eight 0.5A SSR

Open Bd

A007-1732-F4B8

A007-1732-18C2

115/230 VAC

Dual Sw dc

Open Bd

A007-1732-F4C2

A007-1732-18C8

115/230 VAC

Eight Sw dc

Open Bd

A007-1732-F4C8

A007-1732-18K2

115/230 VAC

Dual 0.5A SSR

Open Bd

A007-1732-F4K2

A007-1732-18K8

115/230 VAC

Eight 0.5A SSR

Open Bd

A007-1732-F4K8

Note 1: Retrofit controller requires a substitution of a 100 Ohm DIN RTD sensor.
Note 2: Mounting and dimensions of retrofit controller are different. Verify that sufficient panel space and depth is available.
Note 3: Retrofit controller outputs are different. Add external interposing mechanical or solid state relay if applicable.
Note 4: Retrofit controller has a programmable, not fixed set point. Lock set point using controller's lockout parameter.
Note 5: For DIN rail mounting or sub-panel mounting, purchase DIN rail adapter p/n 0822-0586-P001 for 1/32 DIN or p/n 0822-0586-P002 for 1/16 DIN.
Note 6: Add a quencharc suppressor, Watlow p/n 0804-0147-0000, for inductive loads.
Note 7: Retrofit does not have equivalent action (as example, no manual reset)
Note 8: Retrofit controller does not have dual dial scale.
Note 9: Hardware lockout is not available on retrofit.
Note 10: Retrofit controller does not have user selectable line voltage.
Note 11: Retrofit does not support remote set point or retransmit. If wires are on these pins, select a different retrofit.
Note 12: Retrofit controller does not have user selectable control action.
Note 13: Solid state sensor required for humidity. See http://www.vaisala.com
Note 14: Retrofit controller does not have user selectable control mode.

Note 15: Use auxiliay event board A007-1732-F4B8

Note 16: Retrofit communications are different, consult specifications.

Note 17: Verify retrofit input range matches application.
