*1 The Soft OFF refers to the state that Windows
®
has been shut down and the power is provided only
for the electric circuit to boot system. This Soft OFF State is different from what is System Standby
set by Windows
®
.
Switch
No.
Description
ON
OFF
Notes
1
Used for the system.
Reserved
Reserved Factory Settings: ON
2
Used for the system.
Reserved
Reserved Factory Settings: OFF
3
Used for the system.
Reserved
Reserved Factory Settings: ON
4
Used for the system.
Reserved
Reserved Factory Settings: OFF
5
Used for the system.
Reserved
Reserved Factory Settings: OFF
6
Changes Reset SW
mode.
Power
button
Reset SW Factory Settings: OFF
7
Used for the system.
Reserved
Reserved Factory Settings: OFF
8
Changes COM2
(RI <---> +5V).
(enabled only when RS-
232C mode)
+5V
Output
RI
Factory Settings: OFF
9
Changes a Master/
Slave setting for
Primary CF Card
Interface.
Slave
Master
Factory Settings: OFF
*1
10
Used for the system.
Reserved
Reserved Factory Settings: OFF
Table 1) System Set Switches
*1 Be sure to use NO.9 switch with factory settings (OFF).
Switch
No.
Description
ON
OFF
RS-
232C
RS-
422
RS-
485
1
Changes COM2's
communication
method
RS-232C
RS-422/RS-485 ON
OFF
*1
2
Changes COM2's
communication
method
RS-422/RS-485
RS-232C
OFF
ON
ON
3
Changes COM2's
communication
method
RS-422/RS-485
RS-232C
OFF
ON
ON
4
Changes TX data's
output mode
TX data output is
controlled via the
RTS signal.
TX data output
is NOT
controlled via
the RTS signal.
(normally
output)
OFF
ON/
OFF
ON/
OFF
