Take Apart Screw Matrix - 2
Screw Matrix
There are 49 screws
installed in these
PowerBooks, including the
hard drive bracket. The
number of screws in the
displays will vary with the
size and manufacturer of
the display.
Trackpad (2) Hold Down (2) Bottom Cable (2) PMU Board (1)
Stiffener (1)
Screw Matrix —Bottom Case Assembly
Bottom Case Short (2)
Under Bottom Case (3) Stiffener Top (1) Power Supply (1)
I/O Door (4)
0 1
1
8 3
8 5
8 1
2 3
4 1
4
Bottom Case (4 total) Long (2)
PC Cardcage (4)
Eject Arms (2) Heat Sink (1) Modem (1)
PC Eject Switch (2) Fan Cover (4)
Scale
