FC8001
Terrestrial Digital Multimedia Broadcast
RF tuner & Demodulator
consumption.
1.5.8. CODEC Interface
ü Left-Justified / Right-Justified / I2S
ü Serial Output Data : 24bit / 20bit / 16bit
ü I2S : support Master / Slave mode
ü Auto Detection for MPEG-1 (LRCK=48KHz) and MPEG-2 (LRCK=24KHz).
ü Capable of MPEG-2 output with 48KHz sampling
ü CRC error check
ü PAD data extraction and transmitting to Host
1.5.9. Convolutional De-interleaver
The function of Convolutional De-Interleaver is to transform burst error to random errot. It
should detect sync byte of 204 bytes RS frame.
1.5.10. RS Decoder
RS decoder should adapt (204, 188) shorten RS specification. It is capable of 8 byte error correction
of 204 bytes.
1.5.11. Clock Generator
The DMB Baseband Chip and peripheral clocks operate from a single 24.576MHz oscillator.
