FC8001
Terrestrial Digital Multimedia Broadcast
RF tuner & Demodulator
9.
FC8000 Package Pin Diagram.................................................................................................. 35
9.1.
65 Pin BGA Package Pin map ................................................................................... 36
9.2.
56 Pin MLF and QFN Package Pin map ..................................................................... 37
10. Package Outline...................................................................................................................... 38
10.1.
65 Pin BGA Dimension ............................................................................................. 38
10.2.
56 Pin QFN Dimension ............................................................................................. 40
11. Application Block Diagram....................................................................................................... 43
11.1.
In case of HPI interface ........................................................................................... 43
11.2.
In case of SPI interface............................................................................................ 46
11.3.
In case of I2C interface............................................................................................ 48
