E N V I R O N M E N TA L C O N T R O L S
W P F B / W P F B E S E R I E S F I LT E R E D B O X FA N S & G R I L L E S
K25
www.hubbell-wiegmann.com
Data Subject To Change Without Notice
F E AT U R E S - S P E C I F I C AT I O N S
Industry Standards
UR, cUR, and CE recognized
“WPFBE” Exhaust Grille with Filter Filter Coat “WPFB” Box Fan
C ATA L O G F R E E - F L O W A I R R AT E D N O M I N A L R U N N I N G
WAT T S A B C D E F G H
N U M B E R D E L I V E RY ( C F M ) V O LTA G E ( R P M ) A M P S
W P F B 1 0 0 1 1 5 1 0 5 1 1 5 3 0 0 0 0 . 1 8 1 5
6 . 1 3 7 . 3 8 2 . 3 8 5 . 6 2 6 . 3 8 4 . 1 3 0 . 7 5 7 . 0 0
( 1 5 6 ) ( 1 8 8 ) ( 6 1 ) ( 1 4 3 ) ( 1 6 2 ) ( 1 0 5 ) ( 1 9 ) ( 1 7 8 )
W P F B 1 0 0 2 3 0 1 0 5 2 3 0 3 0 0 0 0 . 1 8 1 5
6 . 1 3 7 . 3 8 2 . 3 8 5 . 6 2 6 . 3 8 4 . 1 3 0 . 7 5 7 . 0 0
( 1 5 6 ) ( 1 8 8 ) ( 6 1 ) ( 1 4 3 ) ( 1 6 2 ) ( 1 0 5 ) ( 1 9 ) ( 1 7 8 )
W P F B 2 0 0 1 1 5 2 1 0 1 1 5 3 3 0 0 0 . 2 9 3 3
7 . 6 3 8 . 8 8 3 . 0 0 7 . 1 2 7 . 8 8 4 . 5 0 1 . 3 1 8 . 5 0
( 1 9 4 ) ( 2 2 6 ) ( 7 6 ) ( 1 8 1 ) ( 2 0 0 ) ( 1 1 4 ) ( 3 3 ) ( 2 1 6 )
W P F B 2 0 0 2 3 0 2 1 0 2 3 0 3 3 0 0 0 . 2 9 3 3
7 . 6 3 8 . 8 8 3 . 0 0 7 . 1 2 7 . 8 8 4 . 5 0 1 . 3 1 8 . 5 0
( 1 9 4 ) ( 2 2 6 ) ( 7 6 ) ( 1 8 1 ) ( 2 0 0 ) ( 1 1 4 ) ( 3 3 ) ( 2 1 6 )
W P F B 5 0 0 1 1 5 5 6 0 1 1 5 1 6 0 0 0 . 8 7 6 0
1 1 . 6 2 1 3 . 0 0 4 . 5 6 1 1 . 1 3 1 1 . 8 8 6 . 8 8 2 . 1 3 1 2 . 5 0
( 2 9 5 ) ( 3 3 0 ) ( 1 1 6 ) ( 2 8 3 ) ( 3 0 2 ) ( 1 7 5 ) ( 5 4 ) ( 3 1 8 )
W P F B 5 0 0 2 3 0 5 6 0 2 3 0 1 6 0 0 0 . 8 7 6 0
1 1 . 6 2 1 3 . 0 0 4 . 5 6 1 1 . 1 3 1 1 . 8 8 6 . 8 8 2 . 1 3 1 2 . 5 0
( 2 9 5 ) ( 3 3 0 ) ( 1 1 6 ) ( 2 8 3 ) ( 3 0 2 ) ( 1 7 5 ) ( 5 4 ) ( 3 1 8 )
W P F B S E R I E S B O X FA N S
C ATA L O G N U M B E R
A B D E F G W *
W I T H F I LT E R F I LT E R O N LY
W P F B E 1 0 0 W P F B M 1 0 0
6 . 1 3 7 . 3 8 5 . 6 2 6 . 3 8 4 . 1 3 0 . 7 5 5 . 6 6
( 1 5 6 ) ( 1 8 8 ) ( 1 4 3 ) ( 1 6 2 ) ( 1 0 5 ) ( 1 9 ) ( 1 4 4 )
W P F B E 2 0 0 W P F B M 2 0 0
7 . 6 3 8 . 8 8 7 . 1 2 7 . 8 8 4 . 5 0 1 . 3 1 7 . 1 6
( 1 9 4 ) ( 2 2 6 ) ( 1 8 1 ) ( 2 0 0 ) ( 1 1 4 ) ( 3 3 ) ( 1 8 2 )
W P F B E 5 0 0 W P F B M 5 0 0
1 1 . 6 2 1 3 . 0 0 1 1 . 1 3 1 1 . 8 8 6 . 8 8 2 . 1 3 1 1 . 1 6
( 2 9 5 ) ( 3 3 0 ) ( 2 8 3 ) ( 3 0 2 ) ( 1 7 5 ) ( 5 4 ) ( 2 8 3 )
W P F B E S E R I E S E X H A U S T G R I L L E S W I T H F I LT E R S
C ATA L O G
D E S C R I P T I O N
N U M B E R
WA X 1 0 10 oz pump spray bottle
F I LT E R C O AT
G
AIR
FLOW
A
B
F
D
D
E
H
C
0.19 DIA 4 PLACES
0.36
D
D
F
E
G
