Modular L-O-X
®
Air Entry Packages
Air Entry Packages with Control Reliable
Energy Isolation
Model
Air Entry
Port Size
C
V
Dimensions
(inches/mm)
Number
Type
In-Out Exh. 1 to 2 2 to 3
Length
Width
Depth
Cat-2 with SV27
RC208-09
FR
1/2
1
6.3
9.2
14.80 (374.9)
11.00 (279.0)
6.60 (167.7)
Cat-2 with SV27
RC208L-09 FRL 1/2 1
6.3 9.2
14.80 (374.9)
11.00 (279.0)
6.60 (167.7)
Cat-3 with DM
1
Series E
RC304-09
FR
1/4
1/2
1.3
2.4
13.00 (330.0)
11.00 (279.0)
5.40 (134.7)
Cat-3 with DM
1
Series E
RC306-09
FR
3/8 1/2 1.9 2.4
13.00 (330.0)
11.00 (279.0)
5.40 (134.7)
Cat-3 with DM
1
Series E
RC304L-09
FRL
1/4
1/2
1.3
2.4
13.00 (330.0)
11.00 (279.0)
5.40 (134.7)
Cat-3 with DM
1
Series E
RC306L-09
FRL
3/8 1/2 1.9 2.4
13.00 (330.0)
11.00 (279.0)
5.40 (134.7)
Cat-4 with DM
2®
Series E
RC404-09
FR
1/4
1/2
1.3
2.4
13.00 (330.0)
11.00 (279.0)
5.40 (134.7)
Cat-4 with DM
2®
Series E
RC406-09
FR
3/8
1/2
1.9
2.4
13.00 (330.0)
11.00 (279.0)
5.40 (134.7)
Cat-4 with DM
2®
Series E
RC404L-09
FRL
1/4
1/2
1.3
2.4
13.00 (330.0)
11.00 (279.0)
5.40 (134.7)
Cat-4 with DM
2®
Series E
RC406L-09
FRL
3/8
1/2
1.9
2.4
13.00 (330.0)
11.00 (279.0)
5.40 (134.7)
* NPT port threads. Specify voltage and hertz when ordering.
Do not use in power press clutch/brake applications.
•
Pre-engineered panel-mounted design with air entry via filter and
regulator “FR”, or filter, regulator, and lubricator “FRL”.
•
Includes 3/2 Normally Closed Sensing Valve which senses poppet position
and state. Electrical feedback via DPST switch (double-pole, single-throw).
•
Applications include Air Dump and Trapped-Pressure Release.
Air Entry Package with 3/2 Normally Closed
Sensing Valve
•
Pre-engineered panel-mounted design with air entry via a filter and
regulator “FR”, or filter, regulator and lubricator “FRL”.
•
Includes DM
2®
Series E Double Valve with Monitoring & Memory:
a) Self-contained dynamic monitoring system requires no further valve
monitoring controls.
b) Dynamic memory of abnormal function prevents unintentional reset with removal
of air or electricity.
•
All necessary features for safety applications are included:
a) Electrical reset valve
b) Status indicator switch for valve condition (ready-to-run) feedback.
•
Pre-engineered panel-mounted design with air entry
via a filter and regulator “FR”, or filter, regulator and
lubricator “FRL”.
•
Includes DM
1
Series E Double Valve with Monitoring:
a) Self-contained dynamic monitoring system requires no further valve
monitoring controls.
b) Ready-to-run: If an abnormality clears itself upon the removal of electricity to both
solenoids, it will be ready-to-run again. It does not remember the abnormality & stay
in a locked-out state until intentionally reset. Therefore, cumulative abnormalities
may go undetected.
c) Status indicator switch for valve condition (ready-to-run) feedback.
Do not use in power press clutch/brake applications.
