Ross Controls MODULAR GENERAL PURPOSE SERIES CP - Manual (Page 2)

www.rosscontrols.com 7
Series CP, CX Solenoid Pilot Controlled Valves
2/2 Valve Dimensions – inches (mm)
0.83
(21.1)
2.85
(72.4)
2.59
(65.8)
2
1
1.16
(29.5)
1.15
(29.2)
2.31 (58.7)
0.52
(13.2)
Pilot Port
10-32 UNF
2.83 (71.9)
3.83 (97.3)
2.83
(71.9)
1 0 1
X-1
1.82
(46.2)
0.92
(23.4)
Side Mounting
5/16-24 UNC 0.73
(18.5)
0.71
(18.0)
1.40
(35.5)
0.38
(9.7)
2.18 (55.4)
0.41
(10.3)
1.01
(55.4)
Ø 0.20 Mounting
Through-Hole
2.10
(53.2)
1.31
(33.3)
4.63
(117.6)
2
5.63
(143.0)
1.72
(43.7)
1.80
(45.7)
Pilot Port
1/8-27 NPT
3.31 (83.8)
4.16 (105.7)
1
3.45
(87.6)
X-1
0.71
(18.0)
1.63
(41.3)
0.89
(22.6)
1.56
(39.6) 2.72 (69.0)
1.00
(25.4)
Ø0.20 Mounting
Through-Hole
2.77
(70.4)
2.61 (66.4)
0.32
(8.1)
0.46 (11.7)
Port Sizes: 3/8 & 1/2
Port Sizes : 3/4 & 1
2.69
(68.3)
8.52
(216.4)
X-1
2
1
5.37 (136.6)
6.50
(165.1)
2.38 (60.4)
3.75 (59.7)
1.50
(38.1)
Pilot Port
1/8-27 NPT
0.75
(19.1) 2.38 (60.3)
1.25
(31.8)
3.36 (84.4)
1.55
(39.4)
4.55 (115.6)
5.00
(127.0)
1.50
(38.1)
0.28
(7.1)
0.88 (22.2)
Ø0.20 Mounting
Through-Hole
Port Sizes: 1 1/4 & 11/2
Part Numbers of Electrical Connectors
Valve Port Connector Only Connector Pre-wired*
Type Size 24 volts DC 110 volts AC 24 volts DC 110 volts AC
2/2 1/2 - 1 2306K77W 2306K77Z 2307K77W 2307K77Z
2/2 11/2 - 21/2 936K87W 936K87Z 720K77W 720K77Z
3/2 1/2 2306K77W 2306K77Z 2307K77W 2307K77Z
3/2 NC 1 936K87W 936K87Z 720K77W 720K77Z
3/2 NO 1 267K77W 267K77Z 382K77W 382K77Z
*Pre-wired connectors are lighted and include a 2 meter (61/2 ft.) cord.
ELECTRICAL CONNECTORS:
For Series CP, CX Solenoid Pilot Controlled Valves.
3/8 & 1/2 3/4 & 1 1 1/4 & 11/2 2 & 2 1/2
