Installation instructions – Reelcraft Safe-T-Reel Welding Cable Reels (T-14xx-x) User Manual
Page 2
Safe-T-Reel Welding Cable Reels
Page 2
www.reelcraft.com
INSTALLATION INSTRUCTIONS
Inspection
Unpack and inspect reel for damage. Turn the reel by hand to check for smooth operation. Check for completeness.
Figure 1
Figure 2
Mounting
Note: Ensure that only a qualified electrician installs/services this equipment.
1. Four 1/2” diameter mounting holes are located at the base of the reel. Mount reel using four (customer supplied) bolts;
tightening them securely to ensure a solid, rigid attachment. (Figure 1)
Electrical
Note: Observe any applicable NEC, OSHA, and local electrial codes when installing this equipment.
1. Attach a cable lug (customer supplied) to the end of the outlet cable.
2. Mount lug to collector ring assembly using one 1/2-13 UNC bolt. (Figure 2)
