Reelcraft Series H37000 Hose Reels - Manual (Page 5)

ITEM DESCRIPTION QTY. CH37118 L CH37122 L CH37128 L EH37118 L12D EH37122 L12D EH37128 L12D
1 Set Screw (3/8-16 x 3/8) 1 300089 300089 300089 ------ ------ ------
2 Spindle Shaft (18" Lg) 1 262334-18 262334-18 262334-18 262334-18 262334-18 262334-18
3 Self Tapping Screw (5/6-12 x 5/8) 9 S317-31 S317-31 S317-31 S317-31 S317-31 S317-31
4 Hub & Bearing Assembly 2 602587 602587 602587 602587 602587 602587
5 Lock Handle Assembly 1 280109 280109 280109 280109 280109 280109
6 Nyloc Nut (5/16-18) 8 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7
7 Spool Flange 2 260399-3 260399-3 260399-3 260399-3 260399-3 260399-3
8 Tie Rod 4 260402-300 260402-400 260402-500 260402-300 260402-400 260402-500
9 Spool Spacer 1 261775-3 261775-4 261775-5 261775-3 261775-4 261775-5
10 Hex Flange Nut w/Insert (5/16-18) 4 261650-2 261650-2 261650-2 261650-2 261650-2 261650-2
11 Hex Nyloc Nut (3/8-16) 1 S85-8 S85-8 S85-8 S85-8 S85-8 S85-8
12 Spindle 1 262454 262454 262454 262454 262454 262454
13 O-Ring (1.350 ID) 1 S200-324 S200-324 S200-324 S200-324 S200-324 S200-324
14 Gooseneck (1" NPT) 1 262455-1NPT 262455-1NPT 262455-1NPT 262455-1NPT 262455-1NPT 262455-1NPT
15 Socket Head Cap Screw
(5/16-18 w 3/4)
4 S7-51 S7-51 S7-51 S7-51 S7-51 S7-51
16 Hub & Bearing Assembly 1 602588 602588 602588 602588 602588 602588
17 Snap Ring (1.214 ID) 1 S140-31 S140-31 S140-31 S140-31 S140-31 S140-31
18 Hex Head Cap Screw
(5/16-18 x 3/4)
4 S2-53 S2-53 S2-53 S2-53 S2-53 S2-53
19 Swivel (1" x 1") Aflas 1 600682 600682 600682 600682 600682 600682
20 Side Frame 2 260403 260403 260403 260403 260403 260403
21 Cross Brace 2 261501-3 261501-4 261501-5 261501-3 261501-4 261501-5
22 Lock Nut (5/16-18) 8 300107 300107 300107 300107 300107 300107
23 Hex Cap Screw (5-16-18 x 2) 8 S2-51 S2-51 S2-51 S2-51 S2-51 S2-51
24 Hex Nyloc Nut (3/8-16) 1 S85-8 S85-8 S85-8 S85-8 S85-8 S85-8
33 Drive Chain 1 ------ ------ ------ 260406 260406 260406
34 Nyloc Nut (3/8-18) 4 ------ ------ ------ S85-8 S85-8 S85-8
35 Flat Washer (3/8 ID) 4 ------ ------ ------ S350-6 S350-6 S350-6
36 Motor 1 ------ ------ ------ 260583 260583 260583
37 Motor Spacer 1 ------ ------ ------ 260456 260456 260456
38 Motor Gear 1 ------ ------ ------ 260434 260434 260434
39 Flat Washer (5/16 ID) 4 ------ ------ ------ 300039 300039 300039
40 Hex Cap Screw (3/8-16 x 1-1/2) 4 ------ ------ ------ S347-67 S347-67 S347-67
41 Flange Nut (10-32) 6 ------ ------ ------ S79-3 S79-3 S79-3
42 Spool Gear (112T) 1 ------ ------ ------ 260407 260407 260407
43 Gear Spacer 6 ------ ------ ------ 260410 260410 260410
44 Flat Cap Screw (10-32 x 1-1/8) 6 ------ ------ ------ S27-112 S27-112 S27-112
Series H37000 Hose Reels
www.reelcraft.com Page 5
