Item

#

Description

#

Req. UR7800 OLB

UR7800 OLB70

UR7830 OLB

UR7830 OLB70

UR7850 OLB

1

Sheave Assembly

1

S260011

S260011

S260011

S260011

S260011

2

Drive Spring Assembly

1

S260037

S260037

S260037

S260037

S260037

3

Arbor Key

1

261275

261275

261275

261275

261275

4

Spring Arbor

1

261274

261274

261274

261274

261274

5

Spring Case Gasket

1

S260069

S260069

S260069

S260069

S260069

6

Spring Case Stud

1

S260031

S260031

S260031

S260031

S260031

7

Spring Case & Ratchet Ass'y

1

S260074

S260074

S260074

S260074

S260074

8

3/8-24 Hex Jam Nut

1

S76-106

S76-106

S76-106

S76-106

S76-106

9

10-32 Hex Nut

6

S300011

S300011

S300011

S300011

S300011

10 Main Shaft

1

602283

262501

602283

262501

602283

12 Base Assembly

1

S600016

S600016

S600016

S600016

S600016

13 Guide Arm Assembly

1

S600017

S600017

S600017

S600017

S600017

14 5/16-18 Lock Nut

4

300107

300107

300107

300107

300107

15 1/2-20 Hex Flange Nut

1

S280-8

S280-8

S280-8

S280-8

S280-8

16 10-32 Nyloc Nut

1

S82-15

S82-15

S82-15

S82-15

S82-15

17 Latch Pawl Assembly

1

S600018

S600018

S600018

S600018

S600018

18 Swivel Assembly

1

600375-2

602441-2

600375-2

602441-2

600375-2

19 Latch Spring

1

S260067

S260067

S260067

S260067

S260067

20 10-32 Shoulder Screw

1

S393-2

S393-2

S393-2

S393-2

S393-2

Hose Bumper Assembly

1

A2-HR1004-3

A2-HR1004-3

A2-HR1004-3

A2-HR1004-3

A2-HR1004-3

Hose Assembly

1

None

None

601107-30

601101-30

601107-50

Item

#

Description

#

Req. UR7850 OLB70

UR7900 OLB

UR7915 OLB

UR7925 OLB

1

Sheave Assembly

1

S260011

S260011

S260011

S260011

2

Drive Spring Assembly

1

S260037

S600023

S600023

S600023

3

Arbor Key

1

261275

261275

261275

261275

4

Spring Arbor

1

261274

261274

261274

261274

5

Spring Case Gasket

1

S260069

S260069

S260069

S260069

6

Spring Case Stud

1

S260031

S260031

S260031

S260031

7

Spring Case & Ratchet Ass'y

1

S260074

S260074

S260074

S260074

8

3/8-24 Hex Jam Nut

1

S76-106

S76-106

S76-106

S76-106

9

10-32 Hex Nut

6

S300011

S300011

S300011

S300011

10 Main Shaft

1

262501

262448

262448

262448

12 Base Assembly

1

S600016

S600016

S600016

S600016

13 Guide Arm Assembly

1

S600017

S600017

S600017

S600017

14 5/16-18 Lock Nut

4

300107

300107

300107

300107

15 1/2-20 Hex Flange Nut

1

S280-8

S280-8

S280-8

S280-8

16 10-32 Nyloc Nut

1

S82-15

S82-15

S82-15

S82-15

17 Latch Pawl Assembly

1

S600018

S600018

S600018

S600018

18 Swivel Assembly

1

602441-2

602378-2

602378-2

602378-2

19 Latch Spring

1

S260067

S260067

S260067

S260067

20 10-32 Shoulder Screw

1

S393-2

S393-2

S393-2

S393-2

Hose Bumper Assembly

1

A2-HR1004-3

A3-HR1004-3

A3-HR1004-3

A3-HR1004-3

Hose Assembly

1

601101-50

None

601092-15

601092-25
