Series 5000 Spring Driven Hose Reels

Page 2

www.reelcraft.com

Item # Part # # Req.

Description

Item # Part # # Req.

Description

Item # Part # # Req.

Description

1

500102

1

Case and Cover Assembly

14

300070

4

1/4-20 Nyloc Nut

25

300002

7

10-32 x 1/2” Screw

2

HR2012

1

Hose Guide Assembly

15

500101

1

Base Assembly

26

S400012

1

Latch Bushing

3

300001

4

10-32 x 3/8” Screw

16 S505740

1

Drive Spring Assembly

27

400020

1

O-ring

6

300031

2

1” Snap Ring

17 S261360

1

Spring Case Stud

28

S400109

1

Latch Plate Assembly

7

300034

4

Spacing Washer

18

500103

1

Spring Case Assembly

29

300035

1

10-32 x 1” Screw

8

S295-102

3

1/4-10 x 5/8” Screw

19

300006

1

3/8-16 x 1/2” Set Screw

30

3-117440

1

U-bolt Hose Clamp

9

260022

1

Sheave Flange

20

300011

7

10-32 Hex Lock Nut

31

261650-1

2

1/4-20 Nyloc Nut

10

500006

1

Sheave Disk

21

S82-15

1

10-32 x 3/8” Nyloc Nut

32

500008

1

Main Shaft

11

S500019

1

Latch Cam

22 S400021

1

Latch Bumper

37

S260019

1

Guide Roller and Pin Kit

12

S260648

1

Spring Arbor

23

S32-136

1

10-24 x 3/8” Screw

13

500004

1

Reel Cover

24 S400018

1

Latch Spring

Item #

Description

# Req.

A5800 ELP

A5800 EMP A5816 EMP

A5825 ELP

A5825 EMP

4

90° Street Ell

1

None

S257-26

S257-26

None

S257-26

5

90° Street Ell

1

None

260749

260749

None

260749

33

90° Street Ell

1

300010

None

None

300010

None

34

Swivel Ass’y

1

S600887-1

S600887-1

S600887-1

S600595-1

S600595-1

35

Hose Ass’y

1

None

None

40-260043

601020-25

21-260043

36

Hose Bumper Ass’y

1

None

None

2-HR1004-3 2-HR1004-3 2-HR1004-3

Hose I.D. and Length

None

1/2’ x 25’

None

1/2” x 16’

1/2” x 25’

Reel Inlet Connection

3/8” M.P.T. 3/8” M.P.T. 3/8” M.P.T. 3/8” M.P.T. 3/8” M.P.T.

Max. Operating Pressure

300 P.S.I.

200 P.S.I.

3000 P.S.I.

2000 P.S.I.

2000 P.S.I.

Max. Operating Temperature

150°F

150°F

210°F

210°F

210°F
