Main SWitCH on BUt not Lit
1. CB tripped
a. Reset CB
2. Unit not plugged into main power.
a. Plug into main power source.
3. No power in incoming line.
a. Check outlet.
b. Check power cord.
4. Loose wiring
a. Check terminals and connections.
Motor CreepS in Stop poSition
1. “Min” speed pot on RAMM
board out of adjustment.
Unit tUrnS BUt Won’t Jog
1. Jog function was not selected
a. Select jog.
2. Jog speed has not been set up
a. Call factory.
Unit on BUt Motor Won’t rUn.
(arMatUre VoLtage preSent –
on raMM BoarD)
1. Check motor wiring
a. Replace motor cord or correct
motor wiring. Call factory.
2. Check motor
a. Worn brushes or motor
defective. Call factory.
b. Check for oil in motor, gear box
seal could have ruptured.
Unit on BUt Motor Won’t rUn.
(no arMatUre VoLtage on
raMM BoarD)
1. Selector switch not in run
position.
a. Turn selector switch to
run position.
2. If running with a dancer arm
control.
a. Check that the external/loop
arm function is in the loop
arm position.
3. If running with external control.
a. Check that the external/loop
arm function is in the
external position.
4. Loop height switch setting
too high.
a. Set height setting to “0”.
5. Percent speed function set
too low.
a. Adjust percent speed
function to 100%.
6. Fuses blown.
a. Check fuses & circuit breaker.
7. No AC voltage at DC drive board.
a. Check wiring.
8. Check Signal voltage between
P2 to P1 on DC drive.
0-6 VDC—RAMM
0-9 VDC—Regen Drive
while moving dancer arm.
a. If there is a signal, check
continuity between I1 & I2.
If no continuity, replace D.C.
drive or call factory.
9. Check pico fuse on 69100804
board (F1).
a. Replace fuse, 1 amp pico
fuse—call factory.
troubleshooting guide
