21
If this screen is displayed then the control cabinet has to be opened and the Pac-Sci
drive has to be checked. To reset the fault, the master on-off switch has to be cycled
which will reset the controller. The material path should be checked for obstruction
and parrallelism to the die. If all this seems to be satisfactory and another fault occurs
the factory should be consulted.
MAIN MENU
F1=JOB # F2=MANUAL
F3=AUTOMATIC CYCLE
F4=REVIEW PARAMETERS
The last section to be covered is the ramp/counters section. To get into this mode,
press the ramp pushbutton and the following screen appears.
SELECT RAMP/COUNTERS
F1=BATCH/TOTAL COUNT
F2=ACCEL/DECEL RAMPS
F4=EXIT TO MAIN MENU
F1=BATCH/TOTAL COUNTS
Pressing the F1 key will bring up the batch/total screen, which is used for presetting
the batch count or resetting the total count. The following screen appears.
BATCH COUNTER=000000
TOTAL COUNTER=000000
SET:F1=BATCH F2=TOTAL
F4=RETURN TO RAMP COUNT
Pressing the F1-batch counter key allows the operator to preset a batch count.
Pressing the F2-total counter key resets the total count to zero. This cannot be
undone so be sure that the counter should be reset to zero before pressing F2 key.
Pressing the F4 key brings up the following screen.
SELECT RAMP/COUNTERS
F1=BATCH/TOTAL COUNT
F2=ACCEL/DECEL RAMPS
F4=EXIT TO MAIN MENU
