If the feed has been properly set up and tested in manual and the press has been
electrically interlocked with the feed, feed switch is wired to the correct terminals, then
pressing the F3 key will display the following screen.

SELECT CONTINUOUS OR
BATCH CYCLE F1=BATCH
F2-CONTINUOUS CYCLE
F4=EXIT TO MAIN MENU

F1=BATCH

If the F1 key was pressed then the servo will be in the auto batch mode and the following
screen appears.

BATCH SETTING=000000
BATCH COUNTER=000000
F1=RESET BATCH COUNT
F4=CONTINUE WITH COUNT

If the F1, reset batch count, is pressed then the batch count will be reset to preset or if the
F4, continue with count is pressed then either way the following screen appears.

AUTOMATIC BATCH=000000
JOB #=XX
LGTH=XXX.XXX SPM=XXX
SPEED=XXX% F4=RETURN

Pressing the F4 key, stops the automatic cycle and the main menu screen appears.
When the automatic screen is displayed, all keys except the F4 key are inactive. Every
time the press cycles and trips the feed switch, the feed will cycle once per the parameters
displayed on the screen. If the feed encounters excessive material drag while feeding or
the material being moved encounters a restriction that stops the material forward
movement then a servo fault can occur. If this happens then the following screen is
displayed.

A DRIVE FAULT HAS OCCURED
NOTE TYPE OF FAULT —
( )

* Example of fault
#2 Motor over temperature

Look up fault code printout listed in this manual.
