18
In order to advance material into the die, using the servo feed, the operator has to be
in the manual mode. Pressing F2 on the keypad will cause the screen to change to the
manual mode screen.
MANUAL MODE F1=INCH
F2=SINGLE FEED MODE
F4=EXIT MANUAL MODE
F1=INCH MODE
Pressing the F1 key will allow the operator to change the current “jog to length” to
“continuous”. Pressing and holding the F2 and F3 button will command the servo to
move the material one programmed feed length. You may press and release the jog
button as many times as you wish to get to the feed length. Pressing F1 will display
the following screen.
JOG: TYPE=JOG-LENGTH
F1=ALTER TYPE OF JOG
F2=FWD
F4=EXIT (MANUAL MODE)
F1=ALTER TYPE OF JOG
Pressing the F1=alter type of jog will allow the operator to change the current “jog to
length” to “continuous”. See below. Pressing and holding the F2 key will command
the servo to move the material at a slow rate of speed for as long as the key is
pressed.
JOG: TYPE=CONTINUOUS
F1=ALTER TYPE OF JOG
F2=FWD
F4=EXIT (MANUAL MODE)
Pressing the F4 key once will reset the program to the manual mode screen.
MANUAL MODE F1=INCH
F2=SINGLE FEED MODE
F4=EXIT MANUAL MODE
CYCLE ROLL WITH KEYS
F2-SINGLE FEED
