20
Pressing F4 once resets the program to the manual mode display. Pressing the F4 key
twice resets the program to the main menu display. If the F4 key was pressed twice then
the following screen is displayed.
MODE SELECT F1=JOB#
F2=MAN F3=AUTO F4=REVIEW
F3=AUTOMATIC CYCLE
If the feed has been properly set up and tested in manual and the press has been
electrically interlocked with the feed, feed and pilot switches wired to the correct terminals.
If the F3 key was pressed then the servo will be in the auto total mode and the following
screen appears.
JOB#=XX LENGTH=000.000
AUTOMATIC CYCLE F4=EXIT
Pressing the F4 key, stops the automatic cycle and the main menu screen appears.
MODE SELECT F1=JOB#
F2=MAN F3=AUTO F4=REVIEW
When the automatic screen is displayed, all keys except the F4 key are inactive. Every
time the press cycles and trips the feed switch, the feed will cycle once per the parameters
displayed on the screen. If the feed encounters excessive material drag while feeding or
the material being moved encounters a restriction that stops the material forward
movement then a servo fault can occur. If this happens then the following screen is
displayed.
DRIVE FAULT: FOR FAULT
CHECK CONTROLLER DISPLAY
