The job number screen displays (3) choices for the operator. In the first choice, F1,
Program parameters, the operator can enter or change the pilots, feed length, strokes per
minute that the press is running and speed of the material movement. In the second
choice, F2=Feed Advisor-Calc, the operator can enter or change the pilots, feed length,
strokes per minute that the press is running and feed arc (free travel of the press in which
the feed can move material without a problem) this then calculates the optimum speed of
the material movement. The third choice, F4=Exit, puts the job number entered in memory
for running at this time. If F1 or F2 was selected one of the following displays will appear:
#=00 FL=000.000 SPM=000 #=00 FL=000.000 SPM=000
VEL=000% PILOTS=0 F4=NEXT ARC=180 PILOTS=0 F4=NEXT
Input or change data at curser Input or change data at curser.
When complete press F4 to exit. When complete press F4 to exit.
Fault window will appear if feed length
is too long for SPM. Feed arc is press free
travel for feeding material. Minimum
arc=10, max=300 degrees.
The % of speed is automatically calculated.
This is the fault window that is displayed if the feed length and strokes per minute are not
within minimum parameters.
FEED PARAMETER OUT
OF RANGE. F4=NEXT
F4=Next this command returns to the previous screen so that the new paremeters can be
entered.
Pressing the F4 key at any time returns you to the main menu.
MODE SELECT F1=JOB#
F2=MAN F3=AUTO F4=REVIEW
SELECT F2=MANUAL
