Rapid-Air SERVO FEED WITH TRANSTERM: C, S, X, HT SERIES User Manual

Page 20

In order to advance material into the die, using the servo feed, the operator has to be in the
manual mode. Pressing F2 on the keypad will cause the screen to change to the manual
mode screen. (Cycle rolls with keys) - If the keypad has keys with open rolls or close rolls
on it then the keys are active at this time and the rolls can be electrically released for
inserting the material into the servo feed.

F1=INCH F2=SINGLE FEED MODE
F3=OPERATE ROLLS F4=EXIT

Pressing the F1 key will let the operator decide the amount of travel each key press or
forward or reverse will produce. The operator can input the amount of travel from .001 to
9.999 inches. Pressing the F2 key will only let the operator make a forward movement the
amount that was programmed for the feed length of the job. Pressing F1 will display the
following screen.

JOB MODE MOVE=X.XXX
F2=FWD F3=REV F4=EXIT (MANUAL MODE)

F1=COINTINUOUS OR JOG TO LENGTH

Pressing the F4 key once will reset the program to the jog mode screen so that jog is now
active. Pressing the F4 key twice will reset the program to the manual mode screen. If the
F4 was pressed twice then the following screen is displayed.

F1=INCH F2=SINGLE FEED
F3=OPERATE ROLLS F4=EXIT

F2=SINGLE FEED

If the operator presses F2 then the following screen is displayed. The single feed mode is
active and every time the F1 key is pressed then the feed will cycle and move the distance
indicated on the feed length line.

FEED TO MOVE 000.000
F1=SINGLE FEED F4=EXIT
