2
CABLE INSTALLATION
1. Unwind cable by rolling it out along the ground to prevent kinking. Securely wrap end of wire
rope, opposite hook, with plastic or similar tape to prevent fraying.
2. Insert the end of the cable opposite the hook end into the hole in the drum barrel. Secure the
cable to the drum barrel using setscrew furnished with winch. TIGHTEN SETSCREW SECURE-
LY.
3. Carefully run winch in the “reel-in” direction. Keeping tension on end of cable, spool all the cable
onto the cable drum, taking care to form neatly wrapped layers.
The wire rope can easily be removed from the drum by loosening the setscrew.
Do not energize cable tensioner on a bare drum. Install cable onto drum before applying air
pressure to the cable tensioner.
