Ramsey Winch PROFILE 6000/8000T - Manual (Page 12)

Solenoid Assembly Parts List
278189 (Profile 6000T & 8000T)
12
Item
No.
Qty. Part No. Description
Item
No.
Qty. Part No. Description
1
1 204281 ASSEMBLY - SOLENOID BRACKET 9 4 416216 SCREW - #10-24NC X 1/2 LG
2 1 289015 ASSEMBLY - WIRE BATTERY CABLE 72" LG 10 10 418014 NUT - HX 1/4-20NC REG Z/P
3 2 289077 ASSEMBLY - WIRE #6 GA X 4.5" BLACK 11 8 418149 LOCKWASHER - 1/4 MED SECT Z/P
4 3 289170 ASSEMBLY - WIRE #2 GA X 29" MTR LEAD 12 2 418514 SPACER - SOLENOID BRACKET
5 1 296594 COVER ASSEMBLY 13 2 440260 STRAP - COPPER
6 1 408271 BRACKET - SOLENOID MOUNTING 14 4 440262 SOLENOID
7 6 414042 CAPSCREW 1/4-20NC X 5/8" HX HD 15 1 440281 ASSEMBLY - WIRE GROUND
8 2 414062 CAPSCREW 1/4-20NC X 1-1/2" GR5 Z/P 16 1 472069 GROMMET
Roller Fairlead
#251183
Included with Profile 6000T & 8000T winches.
Mounting hardware for roller fairlead included
with winch.
