Parts list – Ramsey Winch SCH-8500 User Manual
Page 11
Item No.
Quantity
Part No.
Description
Item No.
Quantity
Part No.
Description
1
1
234206
DRUM ASSEMBLY
28
1
426048
PLUNGER
2
1
338345
END BEARING-MOTOR
29
1
431015
MOTOR COUPLING
3
1
306042
BRAKE PISTON
30
2
432018
FITTING
4
1
315004
CABLE ANCHOR
31
4
438022
BRAKE DISC
5
1
334177
RING GEAR
32
1
442220
GASKET-BRAKE HOUSING
6
1
338297
END BEARING-GEAR HOUSING
33
2
442223
GASKET-MOTOR FLANGE
7
1
338302
BRAKE HOUSING
34
1
456038
FITTING-VENT, BREATHER
8
4
346045
PIN-BRAKE
35
1
458142
MOTOR-18.7 CU.IN.
9
2
350720
TIE PLATE
458144
MOTOR-14.9 CU.IN.
10
1
357179
INPUT SHAFT
36
1
462056
O-RING (SHAFT)
11
4
362296
SPACER-TIE PLATE
37
1
462057
O-RING
12
2
362297
SPACER-FOOT
38
1
462058
O-RING
13
1
362298
SPACER-MOTOR
39
1
462059
BACKUP RING
14
1
402120
BEARING
40
1
462060
BACKUP RING
15
1
402121
BEARING
41
1
462061
O-RING (DRUM)
16
1
412095
BUSHING-MOTOR END
42
1
472052
PLUG
17
1
412096
BUSHING-GEAR HOUSING
43
5
474111
PLATE-SEPARATOR
18
6
414303
BOLT-3/8-16NC X2 1/2,HXHD,GR-5, ZINC
44
1
486081
SEAL-GEAR HOUSING
19
8
414658
BOLT-5/8-11NCX1 1/2LG,HXHD,GR-5, ZINC
45
1
490037
SNAP RING
20
1
414926
SETSCREW-3/8-16NC X1,SOCKET,NYLON
46
6
494110
SPRING-BRAKE
21
3
414935
CAPSCREW-3/8-16NCX2 1/2,HXSOCHD
47
4
494112
SPRING
22
2
414952
CAPSCREW-1/2-13NCX1 1/2LG,SOCHD, ZINC
48
1
509130
BRAKE TUBE
23
1
416016
SETSCREW1/4-20NCX1/4 HX SOCK HD CUP
49
1
516011
VALVE-MOTOR CONTROL
24
1
416080
SETSCREW-5/8-18NF X1 LG,HXSOCHD,CUP
50
1
518037
THRUST WASHER
25
1
418036
NUT-3/8-16 NC,HEX JAM, ZINC
51
1
518047
THRUST WASHER
26
1
418088
NUT-JAM 5/8-18NF HEX HD, ZINC
52
1
518052
THRUST WASHER
27
2
418218
LOCKWASHER-1/2 ID MED SECT, ZINC
53
1
518053
THRUST WASHER
54
1
518054
THRUST WASHER
P
ARTS LIST
9
