Ramsey Winch FORD SUPER DUTY KIT 295950 User Manual
Page 3
3
3. Assemble channel (item # 2) to center unit (item #1) using (2 each
side) 3/8” bolts and locknuts (items # 10 & 11). Do not tighten.
4. Lift grill guard assembly into place between lower support brackets.
Attach using (2 each side) 1/2” bolts and locknuts (item # 16 & 17).
Do not tighten.
5. Loosen upper bumper support bolt and attach upper support bracket
(item # 5) using existing hardware. Do not tighten.
6. Attach upper support bracket to center unit assembly using (1 each
side) 3/8” bolts and locknuts (items #10 &11). Do not tighten.
