Page 6

CONDITIONS POSSIBLE CAUSE CORRECTION
MOTOR RUNS IN ONLY ONE
Defective solenoid or stuck solenoid.
Jar each solenoid to free contacts. Check each solenoid by
DIRECTION
applying power to coil terminal (it should make an audible
click when energized).
Defective remote control switch
Disengage winch clutch, remove remote control switch
plug.
from the socket and jump pins at 8 and 4 o’clock. Motor
should run. Jump pins at 8 and 10 o’clock. Motor should
run.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
MOTOR RUNS EXTREMELY HOT
Long period of operation
Cooling-off periods are essential to prevent
overheating.
Insufficient battery
Check battery terminal voltage under load. If 10 volts or
less, replace or parallel another battery to it.
MOTOR RUNS, BUT WITH
Bad connection
Check battery cable for corrosion; clean and grease.
INSUFFICIENT POWER,
OR WITH LOW LINE SPEED
Insufficient charging system
Replace with larger capacity charging system.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
MOTOR RUNS, BUT DRUM
Clutch not engaged
If clutch engaged but symtoms still exists, it will be
DOES NOT TURN
necessary to disassemble winch to determine cause and
repair.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
MOTOR WILL NOT OPERATE
Defective solenoid or stuck solenoid.
Jar solenoid to free contacts. Check solenoid by applying
power to coil terminal (it should make an audible click
when energized).
Defective remote control switch plug
Disengage winch clutch, remove rem ote control switch
from the socket and jump pins at 8 and 4 o’clock. Motor
should run. Jump pins at 8 and 10 o’clock. Motor should
run.
Defective motor
If solenoids operate, check for voltage at armature post;
replace motor.
Loose connections
Tighten connections on bottom side of hood and on motor.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
MOTOR WATER DAMAGED
Submerged in water or water
Allow to drain and dry thoroughly, then run motor without
from high pressure car wash
a load in short bursts to dry windings.
Cable Installation
Unwind the new cable by rolling it out along the ground, to pre-
vent kinking. Remove old cable and observe the manner in
which it is attached to the drum. Before installing the new cable
assembly, securely wrap the end of the cable with plastic tape
or similar tape to prevent fraying.
Position the cable drum so that the large 13/32" diameter hole
in the motor end drum flange is approximately on the top. Form
a short bend (approximately 1/2" long) in the end of the cable.
Insert the bend into the 13/32" hole in the drum flange and then
carefully run the winch in the "reel in" direction approximately
3/4 revolution until the 1/4" diameter threaded hole in the drum
flange is on top.
Secure the cable to the drum flange using cable anchor and
capscrew shown in the parts drawing on page 7. Securely
tighten the capscrew, but do not over-tighten.
Wind 5 wraps of cable onto the drum. Wind on the rest of the
cable by pulling in a light load to keep the tension constant.
Allow the cable to swivel by using a length of chain or a swivel
block between the cable hook and the load.
Troubleshooting Guide
6
