1. Reconnect the positive power lead from
solenoid to battery.
2. Pull approximately 20 ft of cable off
the winch by hand.
3. Re-engage the winch clutch.
4 Test the remote transmitter. The trans-
mitter has push buttons labeled
according to their function. To operate
the winch, hold “ON/OFF” button for 2 seconds to activate the “IN” and
“OUT” functions. (1 flash indicates transmitter is “ON”, 2 flashes indicate
transmitter is “OFF”).
6. Run winch in the “OUT” direction briefly. Make sure the motor has stopped
fully before reversing to prevent premature solenoid failure. Run winch in
the “IN” direction briefly.
7. Follow instructions in your winch owner’s manual for properly reeling in the
rest of the cable. The transmitter is clearly labeled and a red LED flashes
when the winch is in operation. To turn transmitter off press and hold the
“ON/OFF” button for 2 seconds to disable the transmitter when winch is
not in use. This will pro-long the battery life of the transmitter. The transmit
ter automatically turns off after 20 minutes.
PROGRAMMING THE RECEIVER FOR USE WITH A REPLACEMENT TRANSMITTER
When you purchase a replacement transmitter, it will be necessary to reprogram
your receiver to accept the code for the new transmitter. To reprogram the
receiver, press and hold membrane located in the center of receiver face (area
marked “push”). Press and hold “ON/OFF” button on transmitter for 3 seconds.
Press and hold “OUT” button for 3 seconds or until winch activates.
CAUTION: The center membrane area of the receiver face must only be pressed
when programming a new transmitter.
Testing/Operation
OUT
IN
ON/OFF
LED
3
Transmitter
