Labels
• Wood/Metal installation: Install fasteners according to image. In wood applications, all fasteners
MUST be installed into roof truss or other compatible support beam.
• Concrete installation: Install fasteners according to image. Installation must be done directly on
substrate, and never through any intermediary substrates.
On each side, install
fasteners in locations
indicated on image.
Other fastener layouts
may be used if deemed
acceptable by a
Competent Person.
! WARNING
www.guardianfall.com 1-800-466-6385 6305 S. 231st St., Kent, WA 98032
Skyhook Anchor
Part #: 00315
Compliant with all OSHA 1910, OSHA 1926 Subpart M,
ANSI Z359.1-2007, and ANSI A10.32-2012 regulations.
Prior to use, read and understand all instructions provided
with equipment at time of shipment from manufacturer.
Date of manufacture:
Materials: Powder-coated steel.
Capacity range: 130-310 lbs.
(including all equipment)
Structure must withstand MINIMUM load of 5,000 lbs.
All fasteners, equipment, and connections must be selected and deemed compatible
with the Skyhook Anchor by a Competent Person. Refer to instructions for installation.
Avoid contact with sharp and abrasive edges and surfaces.
Avoid contact with all hazards, including, but not limited to,
electrical shock, corrosive substances, and excessive heat.
Compatible roof pitch:
1/12 - 3/12.
Substrate strength requirements: Wood: 3/4” CDX plywood or better.
Metal: 20ga. or thicker. Concrete: 2000 p.s.i. minimum.
90099 (Rev. A)
! WARNING
www.guardianfall.com 1-800-466-6385 6305 S. 231st St., Kent, WA 98032
Skyhook Anchor
Part #: 00325
Compliant with all OSHA 1910, OSHA 1926 Subpart M,
ANSI Z359.1-2007, and ANSI A10.32-2012 regulations.
Prior to use, read and understand all instructions provided
with equipment at time of shipment from manufacturer.
Date of manufacture:
Materials: Powder-coated steel.
Capacity range: 130-310 lbs.
(including all equipment)
Structure must withstand MINIMUM load of 5,000 lbs.
All fasteners, equipment, and connections must be selected and deemed compatible
with the Skyhook Anchor by a Competent Person. Refer to instructions for installation.
Avoid contact with sharp and abrasive edges and surfaces.
Avoid contact with all hazards, including, but not limited to,
electrical shock, corrosive substances, and excessive heat.
Compatible roof pitch:
4/12 - 6/12.
Substrate strength requirements: Wood: 3/4” CDX plywood or better.
Metal: 20ga. or thicker. Concrete: 2000 p.s.i. minimum.
90100 (Rev. A)
! WARNING
www.guardianfall.com 1-800-466-6385 6305 S. 231st St., Kent, WA 98032
Skyhook Anchor
Part #: 00335
Compliant with all OSHA 1910, OSHA 1926 Subpart M,
ANSI Z359.1-2007, and ANSI A10.32-2012 regulations.
Prior to use, read and understand all instructions provided
with equipment at time of shipment from manufacturer.
Date of manufacture:
Materials: Powder-coated steel.
Capacity range: 130-310 lbs.
(including all equipment)
Structure must withstand MINIMUM load of 5,000 lbs.
All fasteners, equipment, and connections must be selected and deemed compatible
with the Skyhook Anchor by a Competent Person. Refer to instructions for installation.
Avoid contact with sharp and abrasive edges and surfaces.
Avoid contact with all hazards, including, but not limited to,
electrical shock, corrosive substances, and excessive heat.
Compatible roof pitch:
7/12 - 9/12.
Substrate strength requirements: Wood: 3/4” CDX plywood or better.
Metal: 20ga. or thicker. Concrete: 2000 p.s.i. minimum.
90101 (Rev. A)
! WARNING
www.guardianfall.com 1-800-466-6385 6305 S. 231st St., Kent, WA 98032
Skyhook Anchor
Part #: 00345
Compliant with all OSHA 1910, OSHA 1926 Subpart M,
ANSI Z359.1-2007, and ANSI A10.32-2012 regulations.
Prior to use, read and understand all instructions provided
with equipment at time of shipment from manufacturer.
Date of manufacture:
Materials: Powder-coated steel.
Capacity range: 130-310 lbs.
(including all equipment)
Structure must withstand MINIMUM load of 5,000 lbs.
All fasteners, equipment, and connections must be selected and deemed compatible
with the Skyhook Anchor by a Competent Person. Refer to instructions for installation.
Avoid contact with sharp and abrasive edges and surfaces.
Avoid contact with all hazards, including, but not limited to,
electrical shock, corrosive substances, and excessive heat.
Compatible roof pitch:
10/12 - 12/12.
Substrate strength requirements: Wood: 3/4” CDX plywood or better.
Metal: 20ga. or thicker. Concrete: 2000 p.s.i. minimum.
90102 (Rev. A)
DO NO
T REM
O
VE LABELS
If equipmen
t f
ails inspection
IMMEDIA
TEL
Y REM
O
VE FR
O
M SERVICE
User must inspect prior to EACH use. Competent Person must complete
formal inspection every 6 months. Competent Person to inspect and initial.
INSPE
CTION GRID
Date of First Use: __________________. Product lifetime is indefinite as
long as equipment passes pre-use and Competent Person inspections.
YR J F M A M J J A S O N D
20____
20____
20____
20____
20____
5. Connect complete and compatible PFAS to SkyMast Skyhook Connection Point.
