Poly-Tex PT-30 User Manual
Page 9
REV: AD-130626
INSTRUCTIONS:
1. ASSEMBLE HOOPS ON A FLAT SURFACE.
2. SECURE HOOP SECTIONS USING (2) #14 X 3/4" SELF-DRILLING SCREWS.
3. DO NOT INSTALL TRUSS MEMBERS ON THIS FRAME ASSEMBLY
SIDE SECTION
TUBE SECTION
(2) #14 x 3/4"
SELF-DRILLING SCREW
NB1802
CF1013
PT PEAK SECTION (34")
HP3000
TUBE W/SWEDGE 2" x 14GA x 115"
CF1012
PT SIDE SECTION (111")
