Diagramas, F-11, F-11 dibujo de impresi ó n – Lincoln Electric IM861 IDEALARC CV 400-I User Manual
Page 39: Cv 400-i
F-11
DIAGRAMAS
F-11
DIBUJO DE IMPRESI
Ó
N
5-18-90J
N.A.
N.A.
N.A.
N.A.
CUATRO RANURAS EN LA BASE PARA MONTAR
LA SOLDADORA UTILIZANDO TORNILLOS DE 5/16
1.68
N.B.
N.B. CONFIGURACIÓN DE LA AGARRADERA EN MODELOS ANTERIORES
20.05 (509)
19.65 (499)
19.20 (487)
41.58 (1056)
26.00 (660)
3.61 (91)
12.60 (320)
(42.7)
11.99 (304)
3.90 (99)
.28
(7.0)
1.00 (25.4)
23.62 (600)
6.20 (157)
30.95
(786)
1.38
(35)
17.25 (438) (CENTRADO)
21.50 (546)
24.75
(628)
M15665
CV 400-I
