A-1
INSTALLATION
MOBIFLEX 400-MS(/HE) BASE UNIT & LFA 3.1/4.1 MOBILE MANUAL/AUTOMATIC
A-1
TECHNICAL SPECIFICATIONS - Mobiflex 400-MS(/HE) Base Unit (K1741-1, K1741-2)
INPUT
115V/1~/60Hz
MOTOR POWER
DIMENSIONS (See Figure A.1)
0.75 KW (1 HP)
EXTRACTION TYPE
Low vacuum; high volume
AIRFLOW RATE
Max. 735 CFM (1,250 m
3
/h)
FILTER SURFACE AREA
325 ft
2
(30 m
2
)
COMPRESSED AIR CONNECTION
60-75 PSI (4-5 bar)
REQUIRED COMPRESSED AIR QUALITY
Dry and oil-free according to ISO 8573-3 class 6
COMPRESSED AIR CONSUMPTION
Max. 2.1 SCFM (60 nl/min.) (depending on the degree of saturation of the filter)
CLEANING CYCLE TIME
60 min.
SOUND LEVEL
69 db(A) (According to ISO 3746)
INPUT POWER CABLE
20 ft. (6 m)
MAXIMUM RELATIVE HUMIDITY
80%
OPERATING TEMPERATURE
WEIGHT
400-MS: 258 lbs. (117 kgs)
400-MS/HE: 267 lbs. (121 kgs)
FILTER TYPE
400-MS: Self-cleaning cellulose/polyester blend
LongLife filter cartridge with precoat
400-MS/HE: Self-cleaning cellulose/polyester blend
LongLife filter
FILTER CLASS (According to ASHRAE 52.2)
400-MS: Untreated: MERV 11
400-MS/HE: MERV 16
Treated: MERV 15
LENGTH (A)
WIDTH (B)
HEIGHT (C)
47.6 inch (1,210 mm)
31.9 inch (810 mm)
40.2 inch (1020 mm)
MINIMUM
NOMINAL
MAXIMUM
41ºF (5ºC)
68ºF (20ºC)
113ºF (45ºC)
