RPC-6106/6108 Rackmount LCD Workstation
The following IEI backplanes and power supply options are recommended for the
RPC-6106/6108 Rackmount LCD Workstation. For more information about these
backplanes and power supply units, please contact an IEI sales representative or visit the
IEI website ( www.ieiworld.com ).
B.1 RPC-6106/6108 Backplane Options
Table B-1 shows the backplane options for RPC-6106/6108.
PCIe
Model No. SBC Type PCI ISA
x 1 x 4 x 16
PSU
Connector
BP-7S-RS-R30 ISA 0 7 0 0 0 AT
IP-7S-RS-R30 PCISA 4 2 0 0 0 AT
IP-7SA-RS-R30 PCISA 4 2 0 0 0 ATX
HPE-7S1 PCI/PCIe 4 0 2 0 0 ATX
HPE-8S1 PCI/PCIe 4 0 2 0 0 ATX
Table B-1: Backplane Options
B.2 Power Supply Options
Table B-2 shows the power supply options for RPC-6106/6108.
Type Model No. Watt
AT ACE-916AP-RS 150W
ACE-816AP-RS 150W
ACE-4518AP-RS 180W
ATX
ACE-4525AP-RS 250W
Table B-2: Power Supply Options
