AFL2-12A-D525 Series Panel PC
Page 88
Î
IO=2D0h;
IRQ=10
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10
Î
IO=2E0h;
IRQ=10, 11
Serial Port I/O port address is 2E0h and the interrupt
address is IRQ10, 11
Î
IO=2D0h;
IRQ=10, 11
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10, 11
Î
IO=2D8h;
IRQ=10, 11
Serial Port I/O port address is 2D8h and the interrupt
address is IRQ10, 11
Î
IO=2B0h;
IRQ=10, 11
Serial Port I/O port address is 2B0h and the interrupt
address is IRQ10, 11
6.3.6 H/W Monitor
The H/W Monitor menu (BIOS Menu 9) shows the operating temperature, fan speeds and
system voltages.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+49 C
Accuracy: 1. -5 ~ +10 degree around 100 degree.
2. -10 ~ +15 degree around 50 degree.
SYS Temperature :+37 C
CPU FAN Speed :N/A
VCC3V :+3.328 V
V_core :+1.144 V
+1.05S :+1.040 V
Vcc3S :+3.357 V
Vcc5V :+5.045 V
VSB3V :+3.328 V
VBAT :+3.232 V
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 9: Hardware Health Configuration
