Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
CPU Configuration
Processor Type
Intel(R) Atom(TM)
CPU D525 @ 1.80GHz
EMT64 Supported
Processor Speed 1800 MHz
System Bus Speed 800 MHz
Ratio Status 9
Actual Ratio 9
Processor Stepping 106ca
Microcode Revision 263
L1 Cache RAM 2x56 k
L2 Cache RAM 2x512 k
Processor Core Dual
Hyper-Threading Supported
Hyper-Threading [Enabled]
Enabled for Windows XP
and Linux (OS optimized
for Hyper-Threading
Technology) and Disabled
for other OS (OS not
optimized for
Hyper-Threading
Technology).
----------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 4: CPU Configuration
The CPU Configuration menu (BIOS Menu 4) lists the following CPU details:
ƒ Processor Type: Lists the brand name of the CPU being used
ƒ EMT64: Indicates if EM64T is supported by the CPU.
ƒ Processor Speed: Lists the CPU processing speed
ƒ System Bus Speed: Lists the system bus speed
ƒ Ratio Status: Lists the ratio status
ƒ Actual Ratio: Lists the actual ratio
ƒ Processor Stepping: Lists the CPU processing stepping
ƒ Microcode Revision: Lists the microcode revision
ƒ L1 Cache RAM: Lists the amount of storage space on the L1 Cache
ƒ L2 Cache RAM: Lists the amount of storage space on the L2 Cache
ƒ Processor Core: Lists the number of the processor cores
ƒ Hyper-Threading: Indicates if Hyper-Threading is supported by the CPU.
