ƒ LVDS
Î Panel Type
Use the Panel Type to determine the LCD panel resolution. Configuration options are
listed below:
ƒ 1024x768 24b
ƒ 1280x1024 48b
ƒ 1366x768 24b
ƒ 1440x900 48b
ƒ BY HARDWARE D
EFAULT
Î Current Jumper Setting
Shows current value of the hardware jumper setting for the LVDS resolution. This is the
value used when "BY HARDWARE" is selected in the setting above.
3.7.2 Southbridge Configuration
The Southbridge Configuration menu (BIOS Menu 24) the Southbridge chipset to be
configured.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Power Exit
Southbridge Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Audio Controller
[Auto]
Options
Auto
Azalia
AC'97 Audio Only
All Disabled
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 24:Southbridge Chipset Configuration
