AFL-W19A/W19B/17D/W15A-N270 Panel PC
Page 65
3.3.5.2 APM Configuration
The APM Configuration menu (BIOS Menu 10) allows the advanced power management
options to be configured.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Power Exit
APM Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Restore on AC Power Loss
[Last State]
Power Button Mode [On/Off]
Advanced Resume Event Controls
Resume on Keyboard/Mouse
[Disabled]
Resume On Ring [Disabled]
Resume on PCI-Express WAKE# [Enabled]
Resume on RTC Alarm [Disabled]
If the AT/ATX jumper
been set to AT mode
this item will be
changed to "power on"
automatically
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 10: APM Configuration
Î Restore on AC Power Loss [Last State]
Use the Restore on AC Power Loss BIOS option to specify what state the system
returns to if there is a sudden loss of power to the system.
Î
Power Off
The system remains turned off
Î
Power On D EFAULT
The system turns on
Î
Last State The system returns to its previous state. If it was on, it
turns itself on. If it was off, it remains off.
Î Power Button Mode [On/Off]
Use the Power Button Mode BIOS to specify how the power button functions.
Î
On/Off D EFAULT
When the power button is pressed the system is either
turned on or off
