TANK-700 Embedded System
Page 19
Step 2: Align the pluggable CAN-bus terminal block with the CAN-bus terminal block
connector on the TANK-700.
Step 3: Once aligned, insert the pluggable CAN-bus terminal block into the CAN-bus
terminal block connector.
Step 4: Secure the pluggable CAN-bus terminal block to the external interface by
tightening the two retention screws on either side of the terminal block
(Figure 3-5).
Figure 3-5: Pluggable CAN-bus Terminal Block Installation
3.4 Pluggable DC-In Terminal Block Installation
To install the pluggable DC-in terminal block, please follow the steps below:
Step 1: Locate the DC-in terminal block connector. The location of the connector is
shown in Figure 1-3.
Step 2: Align the pluggable DC-in terminal block with the DC-in terminal block connector
on the TANK-700.
Step 3: Once aligned, insert the pluggable DC-in terminal block into the DC-in terminal
block connector.
Step 4: Secure the pluggable DC-in terminal block to the external interface by tightening
the two retention screws on either side of the terminal block (Figure 3-6).
