TANK-700 Embedded System
Page 3
1.3 Features
The TANK-700 features are listed below:
ƒ Intel® 32nm mobile Core™ i7/i5/i3 or Celeron® processor
ƒ Intel® HD graphics supports H.264/AVC-MPEG2/VC1, DirectX 10.1 and
OpenGL 3.0
ƒ 2.0 GB of DDR3 memory preinstalled
ƒ Dual Combo Gigabit Ethernet ports (SFP Fiber/RJ-45)
ƒ 8-Channel audio/video capture support
ƒ Dual display via VGA and HDMI
ƒ Dual-band 2.4/5 GHz 802.11a/b/g/n 3T3R MIMO Wi-Fi for high speed
wireless transmission
ƒ Redundant dual DC input (9V~36V)
ƒ CAN-bus interface with isolation
ƒ Two USB 3.0 ports
ƒ Four USB 2.0 ports
ƒ One SATA 6Gb/s port
ƒ Eight COM ports (four with isolation)
ƒ Extended temperature fanless design supports -20 °C~70°C
1.4 Technical Specifications
The TANK-700 technical specifications are listed in Table 1-2.
Specifications
System
CPU
Intel® 32nm mobile Core™ i7/i5/i3 or Celeron® processor
Chipset
Intel® QM67
Memory
1 x 204-pin 1066/1333 MHz dual-channel DDR3 SDRAM SO-DIMM
slot (system max. 4.0 GB)
2.0 GB of DDR3 memory preinstalled
Ethernet Controller Intel® 82579 PHY with Intel® AMT 7.0 support
Intel® 82583V Ethernet controller
